APPLICATION FOR CUB4TC
Relative Temperature Error Display
A customer desires to display the difference between the actual temperature of an oven and the
desired temperature of 475.0 °F. If the temperature of the oven is 464.8 °F the display should read
-10.2 °F. A K type thermocouple is to be used.
The user offset capability of the CUB4TC allows for this type of temperature indication. A key
switch has been installed between PROGRAM and COMM to allow programming of the unit.
Desired oven temp = 475.0 °F, set offset for -475.0. Unit will display the temperature relative
to 475.0 °F.
Programming:
tYPE
=
CJC
dIsp
=
=
YES
0.0 ° F
FLtEr = 1
k
rANGE = 5 ° F
OFSEt = - 475.0 ° F
TROUBLESHOOTING
For further technical assistance, contact technical support at the number listed on the front of the bulletin.
LIMITED WARRANTY
The Company warrants the products it manufactures against defects in materials and workmanship
for a period limited to one year from the date of shipment, provided the products have been stored,
handled, installed, and used under proper conditions. The Company’s liability under this limited
warranty shall extend only to the repair or replacement of a defective product, at The Company’s
option. The Company disclaims all liability for any affirmation, promise or representation with
respect to the products.
The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC against
damages, claims, and expenses arising out of subsequent sales of RLC products or products
containing components manufactured by RLC and based upon personal injuries, deaths, property
damage, lost profits, and other matters which Buyer, its employees, or sub-contractors are or may be
to any extent liable, including without limitation penalties imposed by the Consumer Product Safety
Act (P.L. 92-573) and liability imposed upon any person pursuant to the Magnuson-Moss Warranty
Act (P.L. 93-637), as now in effect or as amended hereafter.
No warranties expressed or implied are created with respect to The Company’s products except those
expressly contained herein. The Customer acknowledges the disclaimers and limitations contained
herein and relies on no other warranties or affirmations.
Red Lion Controls AP
Red Lion Controls
20 Willow Springs Circle
York PA 17402
Tel +1 (717) 767-6511
Fax +1 (717) 764-0839
Red Lion Controls BV
Basicweg 11b
NL - 3821 BR Amersfoort
Tel +31 (0) 334 723 225
Fax +31 (0) 334 893 793
31, Kaki Bukit Road 3,
#06-04/05 TechLink
Singapore 417818
Tel +65 6744-6613
Fax +65 6743-3360
